What is TOGAF Phase C?
Phase C drives further on concept of architecture domains. This phase develops the application architecture and data architecture. Formally Phase C splits treats the Data Architecture Domain and the Application Architecture Domain are individually.
Like Phase B, Phase C builds on the Architecture Vison. There is a twist, Phase C has a further obligation to enable the business architecture. This is not treating the business architecture as requirements, rather to confirm the developing summary targets hold together.
Changes in one domain drive constraints and requirements into other domains. The objective is to find the best set of changes across all domains.
Using the steps of Phase C, architects develop the following knowledge:
- what reference architecture will speed architecture development
- what viewpoints will drive relevant analysis for stakeholder to select between architecture alternatives
- what application architecture models and data models will help find the source of the deficiency and the changes that will address it
- where changes in the application architecture drive change in other domains
- where changes in other domains drive changes in the application architecture
It creates the following central works products:
- views that analyze the candidate information systems architecture in terms of the stakeholder's concerns
- that a current and candidate target application architecture
- application architecture gaps
- candidate work products that change the business
Phase C centers on things like application design, data flow, integration, development approach, build vs buy, and change planning. Proper assessment and understanding of this phase are critical.
What is TOGAF Phase C?
In TOGAF Phase C, you are creating the application architecture. Application architects lead the development of your application architecture. The architectural decisions made in Phase C for application architecture interact with decisions made in every enterprise architecture domain.
Phase C in Action
The Application Architecture will help answer the following questions:
- How the application portfolio enables value capture – Application Development Model
- Where cost is injected into the IT Portfolio - Functional Model
- Where rigidity is injected into the IT Portfolio - Integration Model
- How the enterprise runs – System Model
- Systems required to deliver the product or service – Product Model
- The things an organization must be able to do - Functional Model
- The flow of information to required to perform an enterprise' activities - Integration Model
- The complete activities an enterprise performs, typically grouped to show how they relate to each other – Service Model
- What the software portfolio is – Physical Model
Always keep in mind that you are seeking to improve the organization. Improvement requires change and delivers value. Value and cost of change can be measured. Uncertainty always decreases potential value. Uncertainty always increases cost. We treat uncertainty as a geometric impact. A little uncertainty decreases the potential value a lot.
When reading, keep in mind there are many uses of the same terms. Look for the purpose of the model, and don't get trapped when the label differs from what you would call it. For example, what you call a functional model someone else will call a service. In our enterprise architecture consulting, we always focus on what we are trying to understand, not what the model is called.
Different models will explain different aspects of the enterprise. Together the models and the needed changes form the application architecture.
What is Application Architecture?
An application architecture is a description of your complete software portfolio that tells you when to buy, when to use SaaS, and when to build. It tells you where you should put boundaries between systems. It tells you how you will approach your software lifecycle.
We can guarantee that your current application architecture is not aligned with your business architecture. An application architecture requires a business architecture. Developing the business architecture requires application architects join them engaging with stakeholders.
With the stakeholder and the business architect, the application architect explores how software choices enable and constrain the organization's objectives. We consider potential improvements to understand the immediate and mid-term impact. Together, potential changes that deliver too little, require too much work, or have too much uncertainty, are dropped from the architecture roadmap.
When we are developing enterprise architecture teams, we tell the enterprise architects two central facts about TOGAF Phase C - Application Architecture. First, until you have an Application Development Model, you cannot proceed. Until you know how your application choices enable and constrain your business architecture the details of your applications are pointless. Second, if they believe they need to jump into application functionality and integration, they will always develop a low-quality application architecture.
In a modern digitally transformed enterprise, all architecture domains interact. Choices in one domain enable, deliver, or block outcomes in another domain. Most business objectives depend upon right IT Architecture. Ironically, we can only develop the right application architecture if we have a solid business architecture.
What is the role of the Enterprise Architect in Phase C?
In TOGAF Phase C, the enterprise architect's role is to guard the entire value. Depending upon the skills of the domain architects, the enterprise architect needs to fill-in. For example, an Application Architect may not see the impact of changes in the business architecture. Or they may not articulate a requirement in terms the security architect can act on.
The most important role of the enterprise architect is crossing boundaries. Whether they are domain, skill, or authority boundaries, the enterprise architect needs to cross them.
What is the role of the Application Architect in Phase C?
In TOGAF Phase C, we expect the Application Architect to deliver the domain architecture. That requires developing the models that show the source of the deficiency and how to overcome it. They will lead trade-off analysis with stakeholders to determine the target architecture.
The application architect will need to collaborate with the other domain architects.
Key off the business architecture. Know and understand the Operating Model and the Competency and Automation attributes of the Capability Model.
What is the role of the Security Architect in Phase C?
In TOGAF Phase C, we expect the Application Architect to deliver the domain architecture. That requires developing the models that show the source of the deficiency and how to overcome it. They will lead trade-off analysis with stakeholders to determine the target architecture.
The application architect will need to collaborate with the other domain architects.
Key off the business architecture. Know and understand the Operating Model and the Competency and Automation attributes of the Capability Model.
Keep in mind that deficiencies in one domain are often solved in another, and changes in one domain often impose costs and changes in another.
What is the role of the EA Team in Application Architecture
Keep in mind that deficiencies in one domain are often solved in another, and changes in one domain often impose costs and changes in another.
Interaction with TOGAF Phase B, Phase D, and Phase E
Waterfall approaches do not deliver. Best practice enterprise architecture is not a waterfall activity. The only successful approach requires developing the business architecture, application architecture, data architecture, technology architecture and security architecture simultaneously. Simultaneous development requires an agile approach of just enough to test the cascading constraints.
The classic sequence implied in many TOGAF ADM diagrams is the order we can close architecture development, not start it.
Do not fall into the illusion that 'the business' is in any way separated from its applications, data, and infrastructure. That wasn't true in the past, and in a modern digital enterprise is laughable. That illusion is the fastest way to eliminate enterprise agility or the chance of digital transformation success.
Application architects have a critical role in an enterprise architecture team. Nothing happens in a modern digital enterprise without software. Poor application choices will cripple 'the business.' Application architects are specialists in one architecture domain. They cannot architect their domain without regular engagement with business architects, data, technology, and security architects.
Download Business Leader’s Guide to AI
Download Business Leader’s Guide to Artificial Intelligence Organizations that successfully apply innovative technology have had a competitive advantage. Innovative technology does not come with established success patterns and best practices. Innovative technology is novel and […]
Download the Introduction to the TOGAF Standard, 10th Edition
Download Introduction to the TOGAF® Standard, 10th Edition The TOGAF Standard, 10th Edition makes adoption of enterprise architecture best practices easier. It separates the universal concepts from proven best practice. The standard underscore where to […]
Download Capability-based Planning Guide
Download Capability-based Planning Guide Always drive to realize value. Half an improvement is 100% waste! No one teaches an Eagle to crawl, walk, or run. Eagles Fly! Download Teach your Eagles to Fly: Capability-based Planning […]
Download Business Architecture Capability Assessment Guide
Download Business Architecture Capability Assessment Guide Download a Business Architecture Capability Assessment Guide. Capability-based planning is one of the most powerful business architecture improvement techniques. Best practice of capability-based planning uses capability as a management […]
Download Sample Enterprise Architecture Principles
Download Sample Architecture Principles Download a sample enterprise architecture principles. Enterprise Architecture principles identify how to approach a problem or decision. The approach always drives you towards your enduring priorities. Download Sample Enterprise Architecture Principles […]
Download Enterprise Architecture Governance Guide
Download Enterprise Architecture Governance Guide Download the Enterprise Architecture Governance Guide to understand best practice to direct and control the development of architecture, and change to obtain the expected outcomes. Download Enterprise Architecture Governance Guide […]
Download TOGAF and SABSA Integration
Download TOGAF and SABSA Integration Bring SABSA, the world’s best security architecture framework, and TOGAF, the industry standard enterprise architecture framework together. Download TOGAF and SABSA Integration TOGAF and SABSA Integration Includes SABSA uses a […]
Download Enterprise Architecture Capability Reference Architecture
Download Enterprise Architecture Capability Reference Architecture The Enterprise Architecture Capability Reference Architecture will speed up establishing and enhancing your EA Team. Design your Enterprise Architecture Team for success. Identify and enhance the your enterprise architecture […]
Download Agile Enterprise Architecture Report
Download the Agile Enterprise Architecture Report The Agile Enterprise Architecture Report covers our experience – Agile Enterprise Architecture is real, practical and valuable. We do it every day. Field reports bridge the theoretical concepts and […]
Download Agile Enterprise Architecture Case Study
Download the Agile Enterprise Architecture Case Study Download the Agile Enterprise Architecture Case Study to see an example developing an EA Capability and useful architecture at the same time. We cover all six use cases […]
Phase C Essential Knowledge
All TOGAF ADM Phases lead you to developing the knowledge you need. The outcome of Phase C is the candidate application architecture included within the candidate information systems architecture.
| Output & Outcome | Essential Knowledge |
| The application architecture domain architecture approved by the stakeholders for the problem being addressed, with a set of gaps, and work to clear the gaps understood by the stakeholders. | How the current software portfolio fails to meet the preferences of the stakeholders?
What must change to enable the software portfolio to meet the preferences of the stakeholders? (Gaps) What work is necessary to realize the changes that are consistent with the additional value being created? (Work Package) How stakeholder priority and preference adjust in response to value, effort, and risk of change. (Stakeholder Requirements) |
Table 4 from TOGAF Series Guide: Enterprise Architect's Guide to Developing Architecture
Phase C Bare Bones
In Phase C, we can simplify the work of a application architect to determining how an enterprise should be better. That requires understanding what it is trying to be good at, where it is falling short of the best, and what must change to enable being the best.
The bare bones of Phase C are:
- Knowing how the application portfolio enables capturing value
Every organization has a value chain. Activity that changes an input into something more valuable to its customers. Applications either perform value creation, or they deliver record keeping. Traditionally almost all software delivered record keeping.
You must optimize your software for role - value creation or record keeping. Assume record keeping. Do not confuse the important role of record keeping with value creation.
Knowing the source of cost and complexity
Every application portfolio creates cost and complexity. We think of software as a complex watch-works that was assembled over time. We connected everything to everything. With digital products an ubiquitous IT Services understanding ITFM is a foundational skill.
You must optimize your core portfolio to drive out sustained cost and complexity. You must enable enterprise agility. Modern digital organizations can only improve at the pace of software.
- Knowing how to select software
There are four software models: SaaS, enterprise suites, specialist commercial packages, and custom development. Each has a different cost and optimization model. You need to apply the right software model in the right places.
- Knowing when the software is part of 'the product'
Our organizations deliver a product or service. Software that is 'the product' differs greatly from software that supports the business.
- Knowing the flow of information
People are infinitely flexible. We can decide to share information. We can proactively see a situation and react. Software does exactly what it is told. Software only does what it is told.
Information flow happens around software to get the right thing done. This type of information flow breaks enterprise agility. They cripple efficiency. These flows drive cost.
- Knowing the expectations of software
Sometimes we need a casual record keeper. Sometimes we need an autonomous system. Most of the time we need something that helps without too much overhead. We leverage the concepts and attributes in capability models to guide choices about our application architecture. See the Business Architecture Capability Assessment Guide.
- Know what the organization must do
Every enterprise has a set of processes it must perform: primary value creation, supporting, and administrative. Everyone of them needs software. Everyone of them creates and produces information. You need to know what they are, the information they consume, and who does them.
- What must change to deliver the best application portfolio?
We develop application architecture to improve an organization. Most changes do not make a material difference. Most changes tinker around the edges. Focus your time on material changes that drive meaningful enterprise agility, cost, or value creation.
The three completion essentials of Phase C:
- First, what must change? Change in focus, organizational design, upskilling, outsourcing, in-sourcing, automating. These are all changes. We do them to improve an organization.
- Second, when must it change? Are there dependencies? How about pre-conditions? Are you changing set-the-stage for a later change?
- Third, how will you know if the change succeeded? What is your governance test for success? How will you guard value?
The enterprise architecture stakeholders own all decisions for what must change and when. The application architect owns describing the governance tests to enable the stakeholders to direct the change project, the second and third outcomes.
